Vertical Leather Measuring Machine with Digital Scanner
The vertical leather measuring machine features infrared digital scanning for precise area measurement. Compact design saves floor space. Belt drive with transparent roller flattens curled leather. Accuracy: 0.1 sqft. Single-phase power. Available in working widths from 180-320cm.
Description
High Quality Two Cold Two Hot Toe Molding Machine
Function
Product Overview
The vertical leather measuring machine is a space-saving solution designed for shoe factories and leather product manufacturers. Unlike traditional measuring machines, this model uses belt drive transmission and a transparent centrifugal tube roller to flatten curled leather effectively, improving measurement accuracy. Equipped with advanced infrared digital scanning technology, it delivers reliable and precise measurements.
Main Applications
- Shoe/Bag factory leather measurement
- Leather goods production
- Hide area measurement for inventory management
- Quality control and grading
Key Features
- Compact Vertical Design – Takes small floor space compared to traditional machines
- Infrared Digital Scanning – Advanced scanning technology for superior measurement accuracy
- Belt Drive Transmission – Smooth and reliable operation with stepless speed adjustment
- Transparent Roller – Effectively flattens curled and uneven leather
- Single-Phase Power – Low power consumption, easy to install
- Optional Printer – Auto-printing function for label and sticker output
Technical Specifications
- Working Width: 180-320cm (available in 20cm increments)
- Machine Dimensions (L×W×H): 90×(230-370)×110 cm
- Measurement Accuracy: 0.1 sqft, 0.01 sqm
- Measurement Error: ±0.1% (using standard test plate)
- Control System: Industrial PC with 17″ Dell color monitor
- Communication: Multiple serial ports for printer connection
Available Working Widths
- 180CM – Machine size: 230CM
- 200CM – Machine size: 250CM
- 220CM – Machine size: 270CM
- 240CM – Machine size: 290CM
- 260CM – Machine size: 310CM
- 280CM – Machine size: 330CM
- 300CM – Machine size: 350CM
- 320CM – Machine size: 370CM
Software Features
- Multi-language interface (Chinese/English)
- Displays measured area, piece count, total area, total pieces
- Operator, customer, variety, grade, color settings
- Data transmission to another computer for warehouse management
- Sticker content editable via computer
Parameter
| Scanning technology | Infrared digital scanning |
| Voltage | 220v/50hz |
| Power | 3kw |
| Type | Vertical |
| Width | 180-320cm |
| Accuracy | 0.1 sqft / 0.01 sqm |
| Measurement error | ±0.1% |
